The OWASP Top 10 API Security Risks 2023 has arrived! OWASP's API Top 10 is always a highly anticipated release and can be a key component of API security preparedness for the year. As we discussed in API Security Best Practices for a Changing Attack Surface, API usage continues to skyrocket. As a result, API security coverage must be more advanced than ever.

What are the OWASP Top 10 API Security Risks?

The OWASP Top 10 API Security Risks is a list of the highest priority API based threats in 2023. Let’s dig a little deeper into each item on the OWASP Top 10 API Security Risks list to outline the type of threats you may encounter and appropriate responses to curtail each threat.

1. Broken object level authorization

Object level authorization is a control method that restricts access to objects to minimize system exposures. All API endpoints that handle objects should perform authorization checks utilizing user group policies.

We recommend using this authorization mechanism in every function that receives client input to access objects from a data store. As an additional means for hardening, it is recommended to use cryptographically secure random GUID values for object reference IDs.

2. Broken authentication

Authentication relates to all endpoints and data flows that handle the identity of users or entities accessing an API. This includes credentials, keys, tokens, and even password reset functionality. Broken authentication can lead to many issues such as credential stuffing, brute force attacks, weak unsigned keys, and expired tokens.

Authentication covers a wide range of functionality and requires strict scrutiny and strong practices. Detailed threat modeling should be performed against all authentication functionality to understand data flows, entities, and risks involved in an API. Multi-factor authentication should be enforced where possible to mitigate the risk of compromised credentials.

To prevent brute force and other automated password attacks, rate-limitation should be implemented with a reasonable threshold. Weak and expired credentials should not be accepted, this includes JWTs, passwords, and keys. Integrity checks should be performed against all tokens as well, ensuring signature algorithms and values are valid to prevent tampering attacks.

3. Broken object property level authorization

Related to object level authorization, object property level authorization is another control method to restrict access to specific properties or fields of an object. This category combines aspects of 2019 OWASP API Security’s “excessive data exposure” and “mass assignment”. If an API endpoint is exposing sensitive object properties that should not be read or modified by an unauthorized user it is considered vulnerable.

The overall mitigation strategy for this is to validate user permissions in all API endpoints that handle object properties. Access to properties and fields should be kept to a bare minimum at an as-needed basis scoped to the functionality of a given endpoint.

4. Unrestricted resource consumption

API resource consumption pertains to CPU, memory, storage, network, and service provider usage for an API. Denial of service attacks result from overconsumption of these resources leading to downtime and racked up service charges.

Setting minimum and maximum limits relative to business functional needs is the overall strategy to mitigating resource consumption risks. API endpoints should limit the rate and maximum number of calls at a per-client basis. For API infrastructure, using containers and serverless code with defined resource limits will mitigate the risk of server resource consumption.

Coding practices that limit resource consumption need to be in place, as well. Limit the number of records returned in API responses with careful use of paging, as appropriate. File uploads should also have size limits enforced to prevent overuse of storage. Additionally, regular expressions and other data-processing means must be carefully evaluated for performance in order to avoid high CPU and memory consumption.

5. Broken function level authorization

Lack of authorization checks in controllers or functions behind API endpoints are covered under broken function level authorization. This vulnerability class allows attackers to access unauthorized functionality; whether they are changing an HTTP method from a `GET` to a `PUT` to modify data that is not expected to be modified, or changing a URL string from `user` to `admin`. Proper authorization checks can be difficult due to controller complexities and the numbers of user groups and roles.

Comprehensive threat modeling against an API architecture and design is paramount in preventing these vulnerabilities. Ensure that API functionality is carefully structured and corresponding controllers are performing authentication checks. For example, all functionality under an `/api/v1/admin` endpoint should be handled by an admin controller class that performs strict authentication checks. When in doubt, access should be denied by default and grants should be given on a as needed basis.

6. Unrestricted Access to Sensitive Business Flows

Automated threats are becoming increasingly more difficult to combat and must be addressed on a case-by-case basis. An API is vulnerable if sensitive functionality is exposed in such a way that harm could occur if excessive automated use occurs. There may not be a specific implementation bug, but rather an exposure of business flow that can be abused in an automated fashion.

Threat modeling exercises are important as an overall mitigation strategy. Business functionality and all dataflows must be carefully considered, and the excessive automated use threat scenario must be discussed. From an implementation perspective, device fingerprinting, human detection, irregular API flow and sequencing pattern detection, and IP blocking can be implemented on a case-by-case basis.

7. Server side request forgery

Server side request forgery (SSRF) vulnerabilities happen when a client provides a URL or other remote resource as data to an API. The result is a crafted outbound request to that URL on behalf of the API. These are common in redirect URL parameters, webhooks, file fetching functionality, and URL previews.

SSRF can be leveraged by attackers in many ways. Modern usage of cloud providers and containers exposes instance metadata URLs and internal management consoles that can be targeted to leak credentials and abuse privileged functionality. Internal network calls such as backend service-to-service requests, even when protected by service meshes and mTLS, can be exploited for unexpected results. Internal repositories, build tools, and other internal resources can all be targeted with SSRF attacks.

We recommend validating and sanitizing all client provided data to mitigate SSRF vulnerabilities. Strict allow-listing must be enforced when implementing resource-fetching functionality. Allow lists should be granular, restricting all but specified services, URLs, schemes, ports, and media types. If possible, isolate this functionality within a controlled network environment with careful monitoring to prevent probing of internal resources.

8. Security misconfiguration

Misconfigurations in any part of the API stack can result in weakened security. This can be the result of incomplete or inconsistent patching, enabling unnecessary features, or improperly configuring permissions. Attackers will enumerate the entire surface area of an API to discover these misconfigurations, which could be exploited to leak data, abuse extra functionality, or find additional vulnerabilities in out of date components.

Having a robust, fast, and repeatable hardening process is paramount to mitigating the risk of misconfiguration issues. Security updates must be regularly applied and tracked with a patch management process. Configurations across the entire API stack should be regularly reviewed. Asset Management and Vulnerability Management solutions should be considered to automate this hardening process.

9. Improper inventory management

Complex services with multiple interconnected APIs present a difficult inventory management problem and introduces more exposure to risk. Having multiple versions of APIs across various environments further increases the challenge. Improper inventory management can lead to running unpatched systems and exposing data to attackers. With modern microservices making it easier than ever to deploy many applications, it is important to have strong inventory management practices.

Documentation for all assets including hosts, applications, environments, and users should be carefully collected and managed in an asset management solution. All third-party integrations need to be vetted and documented, as well, to have visibility into any risk exposure. API documentation should be standardized and available to those authorized to use the API. Careful controls over access to and changes of environments, plus what's shared externally vs. internally, and data protection measures must be in place to ensure that production data does not fall into other environments.

10. Unsafe consumption of APIs

Data consumed from other APIs must be handled with caution to prevent unexpected behavior. Third-party APIs could be compromised and leveraged to attack other API services. Attacks such as SQL injection, XML External Entity injection, deserialization attacks, and more, should be considered when handling data from other APIs.

Careful development practices must be in place to ensure all data is validated and properly sanitized. Evaluate third-party integrations and service providers’ security posture. Ensure all API communications occur over a secure channel such as TLS. Mutual authentication should also be enforced when connections between services are established.

What's next?

The OWASP Top 10 API Security Risks template is now ready and available for use within InsightAppSec, mapping each of Rapid7’s API attack modules to their corresponding OWASP categories for ease of reference and enhanced API threat coverage.

Make sure to utilize the new template to ensure best in class coverage against API security threats today! And of course, as is always the case, ensure you are following Rapid7’s best practices for securing your APIs.
