A New Client-Server Communication Protocol, VFS GUI, and More Performance Upgrades Make This The Fastest and Most Scalable Velociraptor Yet

Rapid7 is excited to announce the release of version 0.6.8 of Velociraptor—an advanced, open-source digital forensics and incident response (DFIR) tool that enhances visibility into your organization’s endpoints. This release has been in development and testing for several months and features significant contributions and testing from our community. We are thrilled to share its powerful new features and improvements here today.

Performance Improvements

A big theme in the 0.6.8 release was about performance improvement, making Velociraptor faster, more efficient and more scalable (even more so than it currently is!).

New Client-Server Communication Protocol

When collecting artifacts from endpoints Velociraptor maintains a collection state (e.g. how many bytes were transferred?, how many rows? was the collection successful? etc). Previously tracking the collection was the task of the server, but this extra processing limited the total number of collections it could process.

In the 0.6.8 release, a new communication protocol was added to offload a lot of the collection tracking to the client itself. This reduces the amount of work on the server and allows more collections to be processed at the same time.

To maintain support with older clients, the server continues to use the older communication protocol with them—but will achieve the most improvement in performance once the newer clients are deployed.

New Virtual File System GUI

The VFS feature in Velociraptor allows users to interactively inspect directories and files on the endpoint, in a familiar tree-style user interface. The previous VFS view would store the entire directory listing in a single table for each directory. For very large directories like C:\Windows or C:\Windows\System32 (which typically have thousands of files) this would strain the browser leading to unusable UI.

In the latest release, the VFS GUI uses the familiar paged table and syncs this directory listing in a more efficient way. This improves performance significantly: for example, it is now possible and reasonable to perform a recursive directory sync on C:\Windows, on my system syncs over 250k files in less than 90 seconds.

Inspecting a large directory is faster with paging tables.
Inspecting a large directory is faster with paging tables.

Since the VFS is now using the familiar paging table UI, it is also possible to filter, sort on any column using that same UI.

Faster Export Functionality

Velociraptor hunts and collections can be exported to a ZIP file for easy consumption in other tools. The 0.6.8 release improved the export code to make it much faster. Additionally, the GUI was improved to show how many files were exported into the zip, and other statistics.

Exporting collections is much faster!
Exporting collections is much faster!

Tracing Capability On Client Collections

We often get questions about what happened to a collection that seems to be hung? It is difficult to know why a collection seems to be unresponsive or stopped - it could mean the client was killed for some reason, (e.g. due to excessive memory use or a timeout).

Previously the only way to gather client side information was to collect a Generic.Client.Profile collection. This required running it at just the right time and did not guarantee that we would get helpful insight of what the query and the client binary were doing during the operation in question.
In the latest release it is now possible to specify a trace on any collection to automatically collect client side state as the collection is progressing.

Enabling trace on every collection increases visibility
Enabling trace on every collection increases visibility

Trace files contain debugging information
Trace files contain debugging information

VQL Improvement - Disk Based Materialize Operator

The VQL LET ... <= operator is called the materializing LET operator because it expands the following query into a memory array which can be accessed cheaply multiple times.

While this is useful for small queries, it has proved dangerous in some cases, because users inadvertently attempted to materialize a very large query (e.g. a large glob() operation) dramatically increasing memory use. For example, the following query could cause problems in earlier versions.

LET X <= SELECT * FROM glob(globs=specs.Glob, accessor=Accessor)

In the latest release the VQL engine was improved to support a temp file based materialized operator. If the materialized query exceeds a reasonable level (by default 1000 rows), the engine will automatically switch away from memory based storage into file backed storage. Although file based storage is slower, memory usage is more controlled.

Ideally the VQL is rewritten to avoid this type of operation, but sometimes it is unavoidable, and in this case, file based materialize operations are essential to maintain stability and acceptable memory consumption.

New MSI Deployment Option

On Windows the recommended way to install Velociraptor is via an MSI package. The MSI package allows the software to be properly installed and uninstalled and it is also compatible with standard Windows software management procedures.

Previously however, building the MSI required using the WIX toolkit - a Windows only MSI builder which is difficult to run on other platforms. Operationally building with WIX complicates deployment procedures and requires using a complex release platform.

In the 0.6.8 release, a new method for repacking the official MSI package is now recommended. This can be done on any operating system and does not require WIX to be installed. Simply embed the client configuration file in the officially distributed MSI packages using the following command:

velociraptor-v0.6.8-rc1-linux-amd64 config repack --msi
velociraptor-v0.6.8-rc1-windows-amd64.msi client.config.yaml
Repacking an MSI for windows distribution
Repacking an MSI for windows distribution


If you’re interested in any of these new features, we welcome you to take Velociraptor for a spin by downloading it from our release page. It’s available for free on GitHub under an open-source license.

As always, please file bugs on the GitHub issue tracker or submit questions to our mailing list by emailing You can also chat with us directly on our Discord server.
